Fast food restaurant tabletop self-service ordering terminal equipment with QR scanner printer and POS bracket

“Desktop Ordering Kiosk” – A space-saving smart ordering terminal with vertical design that fits seamlessly on tables/counters. Touchscreen-enabled, completes the entire ordering and payment process in 30 seconds to reduce labor costs. Ideal for high-traffic environments such as fast-food restaurants, beer festivals, cafes and other intensive service scenarios.

Get in touch

1. Basic functions of the software
Support video, pictures, text, scrolling subtitles, office documents and web pages and other materials display;
Support timing switch machine, unattended, 24/7 no rest;
Support full screen and split screen display programs, terminals can be distributed deployment, grouping, sub-regional tree structure;
2.Hardware
Built-in stereo surround sound, sound stereo full;
Using HD LCD panel, with high brightness and contrast;
3.Network support
Support remote monitoring, real-time update of networking content, status monitoring, remote restart, etc.
Support local area network, wide area network and other release programs, terminals can be connected via wired network, WiFi, 4G network, etc.
4.Program release
Meet the needs of wired wireless networking; When there is no network, the program can be updated through the U disk;
Release is simple, only four steps: ① upload material; ② Program production; 3③Program scheduling; 4④program release.

Freestanding Tabletop Self-Service Kiosk
Flexible and Efficient Countertop Service Terminal
Revolutionary Vertical Interaction, Maximizing Spatial Efficiency
Engineered for fast-food chains, cafes, and themed restaurants, the Freestanding Tabletop Self-Service Kiosk features a vertical integrated body structure that can be securely placed on flat surfaces such as dining tables, bars, or food pickup counters.
Multi-Scenario Adaptive Hardware Configuration
Three HD Touchscreen Sizes:
21.5-inch (compact bubble tea shops), 24-inch (standard fast-food restaurants), 27-inch (visual-themed restaurants);
Global Payment Integration System:
The Tabletop Self-Service Kiosk integrates a high-precision QR scanner, NFC sensing zone, and smart bill recognition module, supporting hybrid payment processing (credit cards, e-wallets like Alipay/Apple Pay, and cash). Achieves cross-border payment adaptation within 30 seconds.
Core Value Propositions
5-Minute Rapid Deployment
Occupies only 0.15㎡ of table space. Plug-and-play design enables quick setup for pop-up stores or food festivals.
Omnichannel Data Integration
Real-time synchronization with POS systems, inventory management, and membership databases via Wi-Fi/Bluetooth. Automatically verifies e-coupons and updates sold-out dishes.
Military-Grade Protective Design with Full Metal Body

LCD screen parameters
Resolution 1080(H)×1920(V)
Display color 16.7 M
Brightness 250 cd/㎡
Contrast 1200:1
Viewing Angle (degree) 89/89/89/89 (Typ.)(CR≥10)
Longevity > 50,000 hours
Response time 3ms (typ.)
Android scheme Basic parameters(Upgradable)
Scheme RK3568, quad-core, main frequency up to 2.0GHz
Graphics processing device Mali-G52 Support OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1 Embedded high performance 2D acceleration hardware
RAM 4G
ROM  32G
System Android 11
Web Support Standard: Ethernet, WiFi Optional
USB 2
RJ45 1
TF card slots 1
SIM card slots 1
HDMI input 1
Windoes scheme Basic parameters (Upgradable)
Graphics processing device windows 10/11
RAM 4G
SSD  128G
System windows 10/11 i3 4th
Web Support Standard: Ethernet, WiFi Optional
USB 4
RJ45 1
HDMI input 1
Optional device
Hardware NFC, QR code scanner, 80mm printer
Size 21.5inch,24inch,27inch
Supported media formats
Video playback Support wmv, avi, flv, mpeg
, mkv, mp4, mpg, mov, rm, rmvb, etc
Picture Format JPG, PNG supported
Audio format MP3, WMA
Capacitance parameters
Multi-touch Maximum touch points supported: ≦10 points
Scanning frequency Changes in scanning rate and measurement capacitance: ≥100KHZ
Wake up response time ms Time from finger touch to response: ≦15ms
Touch accuracy mm Deviation between the real position and the position reflected by the touch: ±2.0mm
Linearity Deviation from straight line touch: ±2.0mm
Touch separation mm Distance of two points that can be distinguished: 15mm
Sensitivity The sensitivity of the touch screen (click≤φ6mm, slip≤φ6mm: uniformly≤1.5mm)
Temperature range Operating temperature: -10℃~60℃
Operating power consumption ≥1W
Machine parameters
Exterior materials Aluminum profile + hardware
Exterior color Silver border + black back shell/Black border + black back shell/all white (1 of 3)
Installation floorstanding
Power of the whole machine ≤60W
Input voltage AC 100~240V 50/60Hz
Speaker Stereo L/R, 8 oh5 watts x 2
Working environment 0 ℃ to 40 ℃
Storage environment – 20 ℃ ~ 60 ℃
Accessories
Hex holder, key, power cord,WiFi antenna stick
